Audio-RF Signal Tracer Kit Z-80

Audio-RF Signal Tracer Kit Z-80; PACO Electronics Co. (ID = 884367) Equipment
Audio-RF Signal Tracer Kit Z-80; PACO Electronics Co. (ID = 883829) Equipment Audio-RF Signal Tracer Kit Z-80; PACO Electronics Co. (ID = 883911) Equipment
Audio-RF Signal Tracer Kit Z-80; PACO Electronics Co. (ID = 883913) Equipment Audio-RF Signal Tracer Kit Z-80; PACO Electronics Co. (ID = 883914) Equipment
Audio-RF Signal Tracer Kit Z-80; PACO Electronics Co. (ID = 883915) Equipment Audio-RF Signal Tracer Kit Z-80; PACO Electronics Co. (ID = 962757) Equipment
Audio-RF Signal Tracer Kit Z-80; PACO Electronics Co. (ID = 962758) Equipment
Use red slider bar for more.
Audio-RF Signal Tracer Kit Z-80; PACO Electronics Co. (ID = 883829) Equipment
PACO Electronics Co.: Audio-RF Signal Tracer Kit Z-80 [Equipment] ID = 883829 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model Audio-RF Signal Tracer Kit Z-80, PACO Electronics Co., Inc.; Glendale, NY:

Country:  United States of America (USA)
Manufacturer / Brand:  PACO Electronics Co., Inc.; Glendale, NY
Year: 1960 ?? Category: Service- or Lab Equipment
Valves / Tubes 5: 12AV6 12AU6 12AQ5 12X4 1629
Semiconductors (the count is only for transistors) 1:
Main principle Audio-Amplification
Wave bands - without
Details Loudspeaker + integr.Amplifier
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: Audio-RF Signal Tracer Kit Z-80 - PACO Electronics Co., Inc.;
Material Metal case
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 114 x 51 x 70 inch / 2896 x 1295 x 1778 mm
Notes Soprammobile basso con andamento orizzontale.
Lo strumento consente:
- traccia del segnale nella sezione RF e BF
- ricerca dicause di rumorose (Noise Testing)
- prove per sostituzione (trasformatore di uscita e altoparlante)
- prove di funzionalità di altoparlanti
- test di microfoni, pickup, sintonizzatori ecc.
Net weight (2.2 lb = 1 kg) 6 lb 7 oz (6.438 lb) / 2.923 kg
Source of data - - Data from my own collection
Mentioned in -- Original prospect or advert

Model page created by Biagio Laureti. See "Data change" for further contributors.



All listed radios etc. from PACO Electronics Co., Inc.; Glendale, NY
Here you find 18 models, 18 with images and 9 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
