20 TR

20 TR; Paillard AG; St. (ID = 15187) Radio
20 TR; Paillard AG; St. (ID = 2151214) Radio 20 TR; Paillard AG; St. (ID = 2151215) Radio
20 TR; Paillard AG; St. (ID = 142422) Radio 20 TR; Paillard AG; St. (ID = 142424) Radio
20 TR; Paillard AG; St. (ID = 142423) Radio 20 TR; Paillard AG; St. (ID = 142425) Radio
20 TR; Paillard AG; St. (ID = 625709) Radio 20 TR; Paillard AG; St. (ID = 625711) Radio
20 TR; Paillard AG; St. (ID = 627871) Radio 20 TR; Paillard AG; St. (ID = 711477) Radio
Use red slider bar for more.
20 TR; Paillard AG; St. (ID = 2151214) Radio
Paillard AG; St.: 20 TR [Radio] ID = 2151214 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model 20 TR, Paillard AG; St. Croix:
CH_Paillard_20_vue côté gauche_coll. William FAGUE

Country:  Switzerland
Manufacturer / Brand:  Paillard AG; St. Croix
Year: 1936–1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 2A7 58 2A6 2A5 80
Main principle Superheterodyne (common); ZF/IF 440 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-250 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: 20 TR - Paillard AG; St. Croix
Material Metal case
Dimensions (WHD) 390 x 230 x 170 mm / 15.4 x 9.1 x 6.7 inch
Notes

Für die Allstromausführung siehe Modell 20 TC.

Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Price in first year of sale 215.00 SFr
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Thali-Schemasammlung und Tungsram-Röhrenbestückung.
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
