National AB-110

National AB-110; Panasonic, (ID = 1687565) Radio

National AB-110; Panasonic, (ID = 1687566) Radio

National AB-110; Panasonic, (ID = 1687568) Radio
National AB-110; Panasonic, (ID = 1753823) Radio National AB-110; Panasonic, (ID = 1687369) Radio
National AB-110; Panasonic, (ID = 1753824) Radio National AB-110; Panasonic, (ID = 1753825) Radio
National AB-110; Panasonic, (ID = 1753826) Radio National AB-110; Panasonic, (ID = 1753827) Radio
Use red slider bar for more.
National AB-110; Panasonic, (ID = 1753823) Radio
Panasonic,: National AB-110 [Radio] ID = 1753823 929x559
Select picture or schematic to display from thumbnails on the right and click for download.
For model National AB-110, Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1958 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: MC101 OC45 OC45 OC71 OC72 OC72 OA70 MA23
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / UM-3: 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.5 inch = 6.4 cm
Power out 0.15 W (0.2 W max.)
from Radiomuseum.org Model: National AB-110 - Panasonic, Matsushita,
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 143 x 82 x 46 mm / 5.6 x 3.2 x 1.8 inch
Notes

Model identical to National AT-110 with Japanese "2SA" and "2SB" transistors.

Source of data -- Schematic

Model page created by Daniel Rosha. See "Data change" for further contributors.



All listed radios etc. from Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Here you find 2627 models, 2387 with images and 507 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
