RQ-222 AS

RQ-222 AS; Panasonic, (ID = 758433) R-Player
RQ-222 AS; Panasonic, (ID = 396148) R-Player RQ-222 AS; Panasonic, (ID = 396146) R-Player
RQ-222 AS; Panasonic, (ID = 396151) R-Player RQ-222 AS; Panasonic, (ID = 396143) R-Player
RQ-222 AS; Panasonic, (ID = 396149) R-Player RQ-222 AS; Panasonic, (ID = 396150) R-Player
RQ-222 AS; Panasonic, (ID = 396153) R-Player RQ-222 AS; Panasonic, (ID = 1853792) R-Player
RQ-222 AS; Panasonic, (ID = 1853793) R-Player RQ-222 AS; Panasonic, (ID = 1853794) R-Player
Use red slider bar for more.
RQ-222 AS; Panasonic, (ID = 396148) R-Player
Panasonic,: RQ-222 AS [R-Player] ID = 396148 640x365
Select picture or schematic to display from thumbnails on the right and click for download.
For model RQ-222 AS, Panasonic, Matsushita, National ナショナル (also tubes); Osaka:
Front of recorder Frontseite des Gerätes

Country:  Japan
Manufacturer / Brand:  Panasonic, Matsushita, National ナショナル (also tubes); Osaka
Year: 1971/1972 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 5: 2SB324 2SB324 2SC828 2SC828 2SB324
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110; 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out
from Radiomuseum.org Model: RQ-222 AS - Panasonic, Matsushita,
Material Plastics (no bakelite or catalin)
Dimensions (WHD) 220 x 130 x 45 mm / 8.7 x 5.1 x 1.8 inch
Notes The RQ-222 is a model for the US (110V AC only), and there were two versions made: RQ-222AS and RQ-222DAS. The RQ-222 has several features that were unusual for a portable cassette recorder at the time: a built-in condenser microphone, a battery condition/recording level meter, a tape counter, and an electronically speed-controlled motor in the tape transport. It is called an 'IC' unit, but, like other Panasonic early 'IC' sets, it does not use ICs in the usual sense; the 'ICs' are actually miniature PCB assemblies sealed in plastic enclosures. There were also two versions of the carrying case; this one is the earlier 'slide-in' carrying case. The later version of the carrying case completely enclosed the recorder and had a snap-out flap for cassette access.
Price in first year of sale 80.00 $
Source of data - - Data from my own collection
Literature/Schematics (1) -- Schematic (Schemario di Apparecchi Radio a Transistori Vol. 6° Antonelliana)

Model page created by Todd Stackhouse. See "Data change" for further contributors.
