Penn-C DeLuxe-Five

Pennsylvania Wireless Mfg. Co., Penna Wireless (Penn-C); New Castle, PA

Dati
Forum
Immagini
Collezioni

  • Anno
  • 1925 ?
  • Categoria
  • Radio (o sintonizzatore del dopoguerra WW2)
  • Radiomuseum.org ID
  • 229516

 Specifiche tecniche

  • Numero di tubi
  • 5
  • Principio generale
  • A circuiti accordati (amplif. diretta) senza reazione; 2 Stadi BF
  • N. di circuiti accordati
  • 3 Circuiti Mod. Amp. (AM)
  • Gamme d'onda
  • Solo onde medie (OM).
  • Tensioni di funzionamento
  • Batterie (di accumulatori e/o a secco) / 5 & 45 Volt
  • Altoparlante
  • - Questo apparecchio richiede altoparlante/i esterno/i.
  • Materiali
  • Mobile in legno
  • Radiomuseum.org
  • Modello: Penn-C DeLuxe-Five - Pennsylvania Wireless Mfg. Co.
  • Forma
  • Soprammobile a cassapanca o cassetta, solitamente con coperchio (NON a leggio)
  • Annotazioni

  • Pennsylvania Wireless Company Penn C DeLuxe-Five 5-Tube TRF Receiver.

    Waverange 200 to 600 m.

  • Prezzo nel primo anno
  • 90.00 $
  • Fonte dei dati
  • -- Original prospect or advert
  • Bibliografia
  • Popular Radio, Oct 1925, p.347
  • Autore
  • Modello inviato da Alan Larsen. Utilizzare "Proponi modifica" per inviare ulteriori dati.

 Collezioni | Musei | Letteratura

 Forum

Discussioni nel forum su questo modello: Pennsylvania: Penn-C DeLuxe-Five

Argomenti: 1 | Articoli: 1

Our most active member Alan Larsen has given me the following answer to my questions regarding several "Penn C" (mainly P & M Radio Co. with a "Penn C") models and Pennsylvania companies:


I am doubtful there was a common thread between the 1920 P & M Radio Co. "Penn C" and the ~1924 Pennsylvania Wireless "Penn C" but have no proof. If I had a choice between the two models I would go for the 1920 version. Even though I have a few earlier Pennsylvania Wireless models.  I did discover an issue with the set when I just a simple search for "Penn C." We also have a Penn Radio Manufacturing Co. listed with another deLuxe model with Penn C pictures uploaded to it.

I don't why or how we have the Penn Radio Mfg. Co. Did the Pennsylvania Wireless Mfg. Co. change their name to Penn Radio? Don't know. I am sure the auctioned Penn C was a Penn. Wireless set do to the metal tag as well as the lid label. I would also guess that the pictures listed under the Penn Radio deluxe are of the same radio. It would have been nice to have a closeup picture of the lid label on that set.

I will leave it up to you to figure out what to do with the Penn Radio models. I would probably leave the company (It came from somewhere) and add a note to see the Penn. Wireless Mfg. Co. since there is apparently a connection between the two companies however I doubt there is a connection to the earlier P & M Radio.



Ernst Erb, 15.Jan.13
