• Year
  • 1958 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 176485

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 105 -120 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Power out
  • 5 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: NL-1S - Pentron Corporation; Chicago
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 14 x 10.75 x 16.75 inch / 356 x 273 x 425 mm
  • Notes
  • The Pentron Model NL-1S is an AC operated two speed two track tape recorder and a stacked stereo head and preamplifier assembly.
  • Net weight (2.2 lb = 1 kg)
  • 29 lb 0 oz (29 lb) / 13.166 kg
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
