Caralux PR167
Perdio Electronics: Caralux PR167 [Radio] ID = 149116 720x466
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1964 ? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | 7: AF117 AF117 AF117 OC71 OC81D OC81 OC81 |
|---|
| Main principle | Superheterodyne (common); ZF/IF 470 kHz |
|---|---|
| Wave bands | Broadcast (MW) and Long Wave. |
| Details | |
| Power type and voltage | Dry Batteries / 2 x 4.5 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical |
| Power out | 1 W (unknown quality) |
| from Radiomuseum.org | Model: Caralux PR167 - Perdio Electronics Ltd.; |
| Material | Plastics (no bakelite or catalin) |
| Shape | Portable set > 8 inch (also usable without mains) |
| Dimensions (WHD) | 12.5 x 8 x 3.5 inch / 318 x 203 x 89 mm |
| Notes | A seven transistor battery portable radio covering MW (190 - 560 metres), LW (1150 - 2000 metres) and MW Bandspread (a high frequency section of MW centred on 208 metres Luxembourg). The cabinet is moulded plastic with a metalised plastic grille. Sockets for tape recorder and car aerial. Elliptical loudspeaker 8 x 5 inch. Uses two 4.5 volt AD28 battery packs. |
| Net weight (2.2 lb = 1 kg) | 6.75 lb (6 lb 12 oz) / 3.065 kg |
| Literature/Schematics (1) | - - Data from my own collection |
| Literature/Schematics (2) | Radio And Television Servicing books (R&TVS) |
| Literature/Schematics (3) | ERT Service Chart 1570 dated December 1 1966 |
