• Country
• Great Britain (UK)

• Manufacturer / Brand
• Perdio Electronics Ltd. / Products Ltd.; London, Stanmore

• Year
• 1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 102477

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• OC44 OC45 OC45 OC71 OC72 OC72

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• from Radiomuseum.org
• Model: All Transistor PR5 de Luxe - Perdio Electronics Ltd. /

• Shape
• Portable set > 8 inch (also usable without mains)

• Notes
• Sockets for earphone and car aerial. Also see earlier 5 transistor PR5 model.

• Mentioned in
• -- Original-techn. papers.

• Literature/Schematics (1)
• Trader sheet 1389

• Author
• Model page created by Peter Hoddow. See "Data change" for further contributors.
