• Country
• France

• Manufacturer / Brand
• Perlor Radio; Paris

• Year
• 1954 ??

• Category
• Power supply/conditioner or battery or charger

• Radiomuseum.org ID
• 257663

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• 6AL5 EZ80

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Coffret Alimentation AL5 - Perlor Radio; Paris

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 270 x 200 x 130 mm / 10.6 x 7.9 x 5.1 inch

• Notes

• Alimentation normalement reliée à l'oscilloscope OS7 via un cordon à 6 fils.

  Délivre les tensions suivantes: 6.3 VAC, 6.3 VAC double isolation, 290 VDC et 760 VDC.

  Ces tensions sont aussi accessibles sur des socles de 4 mm.





• Net weight (2.2 lb = 1 kg)
• 4 kg / 8 lb 13 oz (8.811 lb)

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Jean Marchal. See "Data change" for further contributors.
