• Country
• France

• Manufacturer / Brand
• Perlor Radio; Paris

• Year
• 1953 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 127578

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• ECH42 EF41 EBC41 EF41 EM34 EL41 EL41 5Y3

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• 110-240 Volt

• Loudspeaker
• -Loudspeaker incorporated, but system not known. / Ø 24 cm = 9.4 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Concerto - Perlor Radio; Paris

• Shape
• Tablemodel, low profile (big size).

• Notes
• PO GO OC und BE

• Source of data
• -- Original-techn. papers.

• Literature/Schematics (1)
• Buch ûber der Aufbau von 5 radios (Perlor)

• Author
• Model page created by Claude Weeber † 27.5.2010. See "Data change" for further contributors.
