• Country
• Soviet Union

• Manufacturer / Brand
• Petropavlovsk Radio Works

• Year
• 1958 ??

• Category
• Commercial Receiver (may include amateur bands)

• Radiomuseum.org ID
• 108811

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• 6К3 6А7 6К3 6К3 6Е5С 6А7 6Б8С 6П6С 6Б8С 6Ц5С

• Main principle
• Superhet with RF-stage; ZF/IF 465 kHz; 2 AF stage(s)

• Tuned circuits
• 9 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and more than two Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Material
• Metal case

• from Radiomuseum.org
• Model: TPS-58 {ТПС-58} - Petropavlovsk Radio Works

• Dimensions (WHD)
• 390 x 260 x 250 mm / 15.4 x 10.2 x 9.8 inch

• Notes
• LW, MW und 4 mal KW.

• Source of data
• - - Data from my own collection

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Klaus Bayer. See "Data change" for further contributors.
