32B Farm radio Version 3

32B Farm radio; Philco, Philadelphia (ID = 143476) Radio

32B Farm radio; Philco, Philadelphia (ID = 143477) Radio

32B Farm radio; Philco, Philadelphia (ID = 143478) Radio

32B Farm radio; Philco, Philadelphia (ID = 143479) Radio

32B Farm radio; Philco, Philadelphia (ID = 143481) Radio
32B Farm radio; Philco, Philadelphia (ID = 360597) Radio 32B Farm radio; Philco, Philadelphia (ID = 712302) Radio
32B Farm radio; Philco, Philadelphia (ID = 360600) Radio 32B Farm radio; Philco, Philadelphia (ID = 360598) Radio
32B Farm radio; Philco, Philadelphia (ID = 360599) Radio
Use red slider bar for more.
32B Farm radio; Philco, Philadelphia (ID = 360597) Radio
Philco, Philadelphia: 32B Farm radio [Radio] ID = 360597 557x640
Select picture or schematic to display from thumbnails on the right and click for download.
For model 32B Farm radio Version 3, Philco, Philadelphia Stg. Batt. Co.; USA:
..mcclellans.com/Philco32B.htm

Country:  United States of America (USA)
Manufacturer / Brand:  Philco, Philadelphia Stg. Batt. Co.; USA
Year: 1935/1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 39 or 44 36 39 or 44 75 42 84
Main principle Superhet with RF-stage; ZF/IF 260 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW), Police, sometimes also early TV (75-200m).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 32 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 32B Farm radio [Version 3] - Philco, Philadelphia Stg. Batt
Material Wooden case
Shape Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
Notes Philco's model 32 series were 32 volt DC farm radios using a two-band six-tube chassis with a vibrator power supply for B+. The vibrator and rectifier unit was a separate chassis.

There were four versions of the model 32B table radio. Version 1 (1934) was a the flat-front version of the classic cathedral design with spade-shaped speaker opening that was used by Philco in a number of other models in 1933 and 1934. Version 2 (1934) was another cathedral design with a scalloped top. Version 3 (1935) was a shouldered tombstone with a lyre-shaped speaker grill, with three vertical bars through the center of the grill. Version 4 (1935) was another shouldered tombstone design, with a roughly square speaker opening with three vertical bars through the center of the opening, and downward sloping horizontal bars on the sides of the opening.

There were also two consoles, an ornate lowboy 32L (1934) and a floor-type console 32F (1935) with a tulip-shaped speaker grill.
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 5 = ca. 1934 and before
Mentioned in Philco Radio 1928-1942
Literature/Schematics (1) Philco 1928-36 Wiring Diagrams, Parts Lists, and Essential Service Data
Literature/Schematics (2) Machine Age to Jet Age II (page 209.)
Literature/Schematics (3) Cathedral & Tombstone Radios (page 191.)
