42-PT-3

42-PT-3 ; Philco, Philadelphia (ID = 631659) Radio
42-PT-3 ; Philco, Philadelphia (ID = 1826052) Radio 42-PT-3 ; Philco, Philadelphia (ID = 1826054) Radio
42-PT-3 ; Philco, Philadelphia (ID = 1826057) Radio 42-PT-3 ; Philco, Philadelphia (ID = 1826059) Radio
Use red slider bar for more.
42-PT-3 ; Philco, Philadelphia (ID = 1826052) Radio
Philco, Philadelphia: 42-PT-3 [Radio] ID = 1826052 933x658
Select picture or schematic to display from thumbnails on the right and click for download.
For model 42-PT-3, Philco, Philadelphia Stg. Batt. Co.; USA

Country:  United States of America (USA)
Manufacturer / Brand:  Philco, Philadelphia Stg. Batt. Co.; USA
Year: 1942 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 7A8 7B7 7C6 50L6GT 35Z3
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 42-PT-3 - Philco, Philadelphia Stg. Batt
Material Wooden case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Notes According to Ramirez, Philco model 42-PT-3 (wooden cabinet with photofinish front) is one of the very few new models introduced by Philco in early 1942 (after U.S. entrance into WWII). It has the same chassis as model 42-PT2 (bakelite cabinet).
Price in first year of sale 23.00 $
Collectors' prices
Source of data Philco Radio 1928-1942
Circuit diagram reference Rider's Perpetual, Volume 14 = 1944 = before 1943
Literature/Schematics (1) Philco 1942 RMS Yearbook

Model page created by Thomas Albrecht. See "Data change" for further contributors.
