Philco, Philadelphia: 48-805 Code 121 [Radio] ID = 107829 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model 48-805 Code 121, Philco, Philadelphia Stg. Batt. Co.; USA

Country:  United States of America (USA)
Manufacturer / Brand:  Philco, Philadelphia Stg. Batt. Co.; USA
Year: 1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 14Q7 7B7 14B6 50A5 35Y4
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: 48-805 Code 121 - Philco, Philadelphia Stg. Batt
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 265 x 160 x 150 mm / 10.4 x 6.3 x 5.9 inch
External source of data E. Erb 3-907007-36-0
