50-T1401 (Code 121)
Philco, Philadelphia Stg. Batt. Co.; USA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Philco, Philadelphia Stg. Batt. Co.; USA
- Year
- 1950 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 93254
EbayCOM user 21yrsn3kdslater
EbayCOM user 21yrsn3kdslater
EbayCOM user 21yrsn3kdslater
EbayCOM user 21yrsn3kdslater
EbayCOM user 21yrsn3kdslater
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 22
- Valves / Tubes
- 6BC5 or 6AG5 7F8 6AG5 6AG5 6AG5 6AG5 12AU7 6V6GT 12AU7 6BA6 6AU6 7X7 6V6GT 6SN7GT 7B4 6AQ5 6SN7GT 6BG6G 6W4GT 1B3GT 5U4G 12LP4 or 10BP4
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: 50-T1401 - Philco, Philadelphia Stg. Batt
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Notes
-
Philco model 50-T1401 (Code 121) is a 12” b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with VHF tuner 76-5433 or 76-4402-6 and picture tube 12LP4 or 10BP4.
- Source of data
- -- Collector info (Sammler)
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 114, Folder 9 dated 11-50)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
