• Country
• United States of America (USA)

• Manufacturer / Brand
• Philco, Philadelphia Stg. Batt. Co.; USA

• Year
• 1954 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 86692

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 7A8 7B7 7C6 35L6GT 50Y7GT

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast (MW) and Tropical/Marine/Police Band(s) = 150-200m.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 60Hz, 117V=110-120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Bakelite case

• from Radiomuseum.org
• Model: B-1352 - Philco, Philadelphia Stg. Batt

• Shape
• Tablemodel, with any shape - general.

• Notes

• Philco model B-1352 is an AC operated radio-phono combination superheterodyne receiver with 3speed automatic record changer.

• Literature/Schematics (1)
• Beitman Radio Diagrams, Vol. 14, 1954

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 235, folder 9, dated 4-54)

• Author
• Model page created by Juan Antonio Pardo-Alonso. See "Data change" for further contributors.
