G-1706S

Philco, Philadelphia Stg. Batt. Co.; USA

Data
Forum
Pictures
Collections

  • Year
  • 1958
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 72232

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Alternating Current supply (AC) / 105 - 120 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Power out
  • 15 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: G-1706S - Philco, Philadelphia Stg. Batt
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Notes
  • The Philco Model G-1706S is an AC operated 4 Tube Phono Amplifier and a 4 Speed Record Changer. Uses Record Changer M-41 with speeds of 16-2/3, 33-1/3, 45 and 78 RPM. This model has Qty(1) 10" PM woofer and Qty(1) type "S" electrostatic speaker. Cabinet is Blonde, Mahogany or Walnut. The G-1706S is similar to the G-1706 except the function switch has a stereo position and the M-41 record changer has a stereo cartridge. Adding the separate Philco model SA-1500 (Slave amplifier and speakers) completed other stereo channel.
  • Circuit diagram reference
  • Beitman Radio Diagrams Vol. 19, 1959
