19RL270/00-R

19RL270/00-R; Philips Italy; (ID = 1503840) Radio

19RL270/00-R; Philips Italy; (ID = 1503841) Radio

19RL270/00-R; Philips Italy; (ID = 1503842) Radio

19RL270/00-R; Philips Italy; (ID = 1503843) Radio

19RL270/00-R; Philips Italy; (ID = 1503844) Radio

19RL270/00-R; Philips Italy; (ID = 1503845) Radio
Use red slider bar for more.
19RL270/00-R; Philips Italy; (ID = 1503840) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Italy
Manufacturer / Brand:  Philips Italy; Milano (MI)
Year: 1968 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF114 AF115 AF116 AF116 AF116 AC127 AC128 AC128 AC128 AC127 AA119
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.25 W (unknown quality)
from Radiomuseum.org Model: 19RL270/00-R - Philips Italy; Milano MI
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 202 x 103 x 48 mm / 8 x 4.1 x 1.9 inch
Notes Gamme d'onda:
OM: 517 - 1622 kHz.
FM: 87,3 - 104,2 MHz.
Presa auricolare.
Source of data -- Original-techn. papers.

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
