Oscar 19RL375 /00 /00R

Oscar 19RL375 /00 /00R; Philips Italy; (ID = 1505044) Radio

Oscar 19RL375 /00 /00R; Philips Italy; (ID = 1505045) Radio

Oscar 19RL375 /00 /00R; Philips Italy; (ID = 1505046) Radio

Oscar 19RL375 /00 /00R; Philips Italy; (ID = 1505047) Radio

Oscar 19RL375 /00 /00R; Philips Italy; (ID = 1505048) Radio

Oscar 19RL375 /00 /00R; Philips Italy; (ID = 1505049) Radio
Oscar 19RL375 /00 /00R; Philips Italy; (ID = 2027744) Radio Oscar 19RL375 /00 /00R; Philips Italy; (ID = 2027740) Radio
Oscar 19RL375 /00 /00R; Philips Italy; (ID = 2027742) Radio Oscar 19RL375 /00 /00R; Philips Italy; (ID = 2027741) Radio
Oscar 19RL375 /00 /00R; Philips Italy; (ID = 2027743) Radio Oscar 19RL375 /00 /00R; Philips Italy; (ID = 1505052) Radio
Use red slider bar for more.
Oscar 19RL375 /00 /00R; Philips Italy; (ID = 2027744) Radio
Philips Italy;: Oscar 19RL375 /00 /00R [Radio] ID = 2027744 933x641
Select picture or schematic to display from thumbnails on the right and click for download.
For model Oscar 19RL375 /00 /00R, Philips Italy; Milano (MI)

Country:  Italy
Manufacturer / Brand:  Philips Italy; Milano (MI)
Year: 1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF114 AF115 AF116 AF116 AF116 AC127 AC128 AC128 AC128 AC128 AC127 AA119
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.25 W (unknown quality)
from Radiomuseum.org Model: Oscar 19RL375 /00 /00R - Philips Italy; Milano MI
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 202 x 103 x 48 mm / 8 x 4.1 x 1.9 inch
Notes

Gamme d'onda:
OM: 517 - 1622 kHz.
FM: 87,3 - 104,2 MHz.

Mentioned in -- Original-techn. papers.

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
