19TX330A /05B

19TX330A /05B; Philips; Eindhoven (ID = 1332170) Television

19TX330A /05B; Philips; Eindhoven (ID = 1332171) Television

19TX330A /05B; Philips; Eindhoven (ID = 1332172) Television

19TX330A /05B; Philips; Eindhoven (ID = 1332174) Television

19TX330A /05B; Philips; Eindhoven (ID = 1332175) Television

19TX330A /05B; Philips; Eindhoven (ID = 1332176) Television

19TX330A /05B; Philips; Eindhoven (ID = 1332177) Television

19TX330A /05B; Philips; Eindhoven (ID = 1332178) Television

19TX330A /05B; Philips; Eindhoven (ID = 1332179) Television

19TX330A /05B; Philips; Eindhoven (ID = 1332180) Television
19TX330A /05B; Philips; Eindhoven (ID = 588082) Television 19TX330A /05B; Philips; Eindhoven (ID = 588083) Television
19TX330A /05B; Philips; Eindhoven (ID = 588084) Television 19TX330A /05B; Philips; Eindhoven (ID = 588085) Television
19TX330A /05B; Philips; Eindhoven (ID = 588086) Television 19TX330A /05B; Philips; Eindhoven (ID = 588364) Television
19TX330A /05B; Philips; Eindhoven (ID = 588365) Television 19TX330A /05B; Philips; Eindhoven (ID = 904923) Television
19TX330A /05B; Philips; Eindhoven (ID = 904924) Television 19TX330A /05B; Philips; Eindhoven (ID = 904925) Television
Use red slider bar for more.
19TX330A /05B; Philips; Eindhoven (ID = 588082) Television
Philips; Eindhoven: 19TX330A /05B [Television] ID = 588082 640x518
Select picture or schematic to display from thumbnails on the right and click for download.
For model 19TX330A /05B, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1961/1962 Category: Television Receiver (TV) or Monitor
Valves / Tubes 22: PC86 PC88 PCC189 PCF86 ECH83 EF183 EF184 PCL84 PCL85 PCF80 PCL86 DY87 PF86 PL500 PY88 AW47-91
Main principle Superheterodyne (common); ZF/IF 38900 kHz; 2 AF stage(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
Power out 3 W (unknown quality)
from Radiomuseum.org Model: 19TX330A /05B - Philips; Eindhoven tubes
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 480 x 390 x 360 mm / 18.9 x 15.4 x 14.2 inch
Notes Separate VHF-UHF tuners, Memomatic system.
Net weight (2.2 lb = 1 kg) 18.5 kg / 40 lb 12 oz (40.749 lb)
Source of data - - Manufacturers Literature

Model page created by John Hupse † 28.9.20. See "Data change" for further contributors.
