22AR070 /15

22AR070 /15; Philips; Eindhoven (ID = 1595164) Radio

22AR070 /15; Philips; Eindhoven (ID = 1595165) Radio

22AR070 /15; Philips; Eindhoven (ID = 1595161) Radio

22AR070 /15; Philips; Eindhoven (ID = 1595162) Radio

22AR070 /15; Philips; Eindhoven (ID = 1595163) Radio

22AR070 /15; Philips; Eindhoven (ID = 1595166) Radio

22AR070 /15; Philips; Eindhoven (ID = 1595167) Radio

22AR070 /15; Philips; Eindhoven (ID = 1595168) Radio

22AR070 /15; Philips; Eindhoven (ID = 1595169) Radio

22AR070 /15; Philips; Eindhoven (ID = 1595170) Radio
Use red slider bar for more.
22AR070 /15; Philips; Eindhoven (ID = 1595164) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 13: BF324 BF495 BC548 BC337 BC549 BC548 TBA120 TBA820 TCA900
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110-127; 220-240 / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 1.1 W (unknown quality)
from Radiomuseum.org Model: 22AR070 /15 - Philips; Eindhoven tubes
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 227 x 247 x 70 mm / 8.9 x 9.7 x 2.8 inch
Notes

Wave range:
MW: 520 - 1605 kHz.
FM:  87,5 - 108 MHz.
One semicondutor per type listed.



Mentioned in -- Original-techn. papers.

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
