Select picture or schematic to display from thumbnails on the right and click for download.
For model 22RF800 Ch= 22RH781, Philips; Eindhoven (tubes international!); Miniwatt:
Prospeto de 1971

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1971 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 22: BF195 BF195 BF195 BF194 BF194 BF195 BC147 BC149 BC147 AC126 BC147 BC147 BC149C BC148 AC128 AD161 AD162 BC149C BC148 AC128 AD161 AD162 Tr.Gl.=Metal-rectif. AA119 BA102 BZY94
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz; 4 AF stage(s)
Tuned circuits 5 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out 20 W (unknown quality)
from Radiomuseum.org Model: 22RF800 Ch= 22RH781 - Philips; Eindhoven tubes
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1430 x 685 x 360 mm / 56.3 x 27 x 14.2 inch
Notes

Tuner and amplifier unit 22RH781 with 2 x 10 W. Record changer.

Connectors for antennas, record changer, recorder and additional speakers.

Cabinet in palisander, palisander with white front or wenge with white front.
