22RL282/00F

22RL282/00F; Philips Italy; (ID = 1196381) Radio

22RL282/00F; Philips Italy; (ID = 1196382) Radio

22RL282/00F; Philips Italy; (ID = 1196383) Radio

22RL282/00F; Philips Italy; (ID = 1196384) Radio

22RL282/00F; Philips Italy; (ID = 1196385) Radio

22RL282/00F; Philips Italy; (ID = 1196386) Radio

22RL282/00F; Philips Italy; (ID = 1196387) Radio

22RL282/00F; Philips Italy; (ID = 1196388) Radio

22RL282/00F; Philips Italy; (ID = 1196389) Radio

22RL282/00F; Philips Italy; (ID = 1196390) Radio
Use red slider bar for more.
22RL282/00F; Philips Italy; (ID = 1196381) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Italy
Manufacturer / Brand:  Philips Italy; Milano (MI)
Year: 1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF124 AF125 AF125 AF125 AF125 AC127 AC132 AC127 AC132 AA119 BA114
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out 0.25 W (unknown quality)
from Radiomuseum.org Model: 22RL282/00F - Philips Italy; Milano MI
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 254 x 110 x 45 mm / 10 x 4.3 x 1.8 inch
Notes Gamme d'onda:
OL: 150 - 260 kHz.
OM: 517 - 1622 kHz.
FM: 87,5 - 104 MHz.
Net weight (2.2 lb = 1 kg) 0.6 kg / 1 lb 5.1 oz (1.322 lb)
Source of data -- Original-techn. papers.

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
