For model 22RR622 /59, Philips Belgium (Belgien)

Country:  Belgium
Manufacturer / Brand:  Philips Belgium (Belgien)
Year: 1974 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 21:
Main principle Superheterodyne (common)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110 - 127; 220 - 240 / 6 × 1,5 Volt
Loudspeaker
Power out 3.6 W (unknown quality)
from Radiomuseum.org Model: 22RR622 /59 - Philips Belgium Belgien
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 365 x 210 x 90 mm / 14.4 x 8.3 x 3.5 inch
Notes Frequency ranges:
LW 150 - 260 kHz
MW 520 - 1605 kHz
SW 7,10 - 21,75 Mhz, 41 - 13 m; 49 m: 5,95 - 6,20 MHz
FM 87,5 - 104 MHz.
Fine tuning for shortwave.
Recorder stops automatically at the end of the race tape.
25 diodes.
Net weight (2.2 lb = 1 kg) 3.350 kg / 7 lb 6.1 oz (7.379 lb)
External source of data Catalog Philips Audio NL 1974

Model page created by Felice Nicolini. See "Data change" for further contributors.
