• Year
  • 1962 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 205123

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 25
  • Number of Transistors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Details
  • Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 23TX371A /00B - Philips; Eindhoven tubes
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 690 x 490 x 400 mm / 27.2 x 19.3 x 15.7 inch
  • Notes
    • Transformerless audio output stage.
    • 4 standard receiver.
    • Type of loudspeaker: 1 x AD3800AM.
    • VHF channels: E2-E11; F6; F8a.
    • UHF 470-790 MHz.
    • Remote control unit AT6320-03.
    • Light varnished housing.
  • Source of data
  • -- Original-techn. papers.
  • Literature/Schematics (1)
  • Service Manual
  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
