2502; Philips; Eindhoven (ID = 2327427) Radio
Philips; Eindhoven: 2502 [Radio] ID = 2327427 1400x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model 2502, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1927/1928 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: A442 or B442 A415 or B424 B443
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown); 1 Special; 1 AF stage(s)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries / 4 & 150 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: 2502 - Philips; Eindhoven tubes
Material Various materials
Dimensions (WHD) 310 x 180 x 140 mm / 12.2 x 7.1 x 5.5 inch
Notes Neben dem Modell 2501 für Wechselstrom das erste Radiomodell von Philips. Erstmals führt ein Radio auch eine Pentode.
Net weight (2.2 lb = 1 kg) 5.5 kg / 12 lb 1.8 oz (12.115 lb)
Collectors' prices
External source of data E. Erb 3-907007-36-0
Source of data Technisch- Commercieel - Radio Vademecum Staleman
Mentioned in Les Radio PHILIPS de collection
