Kiskombináció 2515

Kiskombináció 2515; Philips; Budapest (ID = 1606440) Radio
Kiskombináció 2515; Philips; Budapest (ID = 586081) Radio Kiskombináció 2515; Philips; Budapest (ID = 1600163) Radio
Kiskombináció 2515; Philips; Budapest (ID = 1606442) Radio Kiskombináció 2515; Philips; Budapest (ID = 1606443) Radio
Kiskombináció 2515; Philips; Budapest (ID = 1606444) Radio Kiskombináció 2515; Philips; Budapest (ID = 1606445) Radio
Kiskombináció 2515; Philips; Budapest (ID = 1606446) Radio Kiskombináció 2515; Philips; Budapest (ID = 1826982) Radio
Kiskombináció 2515; Philips; Budapest (ID = 1905255) Radio Kiskombináció 2515; Philips; Budapest (ID = 1905260) Radio
Use red slider bar for more.
Kiskombináció 2515; Philips; Budapest (ID = 586081) Radio
Philips; Budapest: Kiskombináció 2515 [Radio] ID = 586081 653x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Kiskombináció 2515, Philips; Budapest:
Thanks for Mr.Kósa Endre Hungary! More info: ..szepradiok.hu/detektoros.html

Country:  Hungary
Manufacturer / Brand:  Philips; Budapest
Year: 1929/1930 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: AR4101 PP430 PV495
Main principle TRF with regeneration
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Kiskombináció 2515 - Philips; Budapest
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 170 x 180 x 250 mm / 6.7 x 7.1 x 9.8 inch
Notes

The model Kiskombináció 2515 from Philips has either not started with the tube PP430 or is not from 1928 or our finding about first year for the PP430 is wrong. The most possible reason is that the model 2515 had first the Philips B443 (in 1928). It can well be that Hungary - and other countries - were the test market for the model 2515 in the Netherlands, which seems to be from 1930/31. We change here if we get first hand information that proves the matter (like dated ads).

Net weight (2.2 lb = 1 kg) 7.5 kg / 16 lb 8.3 oz (16.52 lb)
Price in first year of sale 290.00 Pengő
Source of data -- Collector info (Sammler)
Literature/Schematics (4) Reich katalógus, Budapest 1930/31.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
