494-AN; Philips USA (ID = 840377) Radio
Philips USA: 494-AN [Radio] ID = 840377 933x512
Select picture or schematic to display from thumbnails on the right and click for download.
For model 494-AN, Philips USA

Country:  United States of America (USA)
Manufacturer / Brand:  Philips USA
Year: 1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6SA7 6SK7 6SQ7 25C6G 6U5 25Z6G
Main principle Superheterodyne (common)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: 494-AN - Philips USA
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 570 x 295 x 230 mm / 22.4 x 11.6 x 9.1 inch
Net weight (2.2 lb = 1 kg) 8.2 kg / 18 lb 1 oz (18.062 lb)
Source of data - - Data from my own collection

Model page created by José Manuel Silvestre. See "Data change" for further contributors.
