• Country
• Austria

• Manufacturer / Brand
• Philips - Österreich

• Year
• 1983/1984

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 213779

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 13

• Semiconductors
• BF495 BF494 BF495 BF495 BF495 BF495 BF495 BC548 BC548 BC548 BC558 BC548 BC328 TDA1012 TDA1059

• Main principle
• Superheterodyne (common); ZF/IF 468/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 110-127 220-240 / 6 x 1,5 & 1 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Traveller Clock - 4 Band Clock Radio Cassette Recorder D7419 /00/05 - Philips - Österreich

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 350 x 190 x 90 mm / 13.8 x 7.5 x 3.5 inch

• Notes
• 4 Band Clock Radio Cassette Recorder D7419/00, + Quarz Clock.

• Net weight (2.2 lb = 1 kg)
• 1.3 kg / 2 lb 13.8 oz (2.863 lb)

• Price in first year of sale
• 1,990.00 ATS

• Mentioned in
• Philips - Radio TV and Home Entertainment Catalogs (Philips Katalog Österreich 1983)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
