• Country
• Belgium

• Manufacturer / Brand
• Philips Belgium (Belgien)

• Year
• 1934

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 221573

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• AK1 AF2 AB1 E446 E443H 506

• Main principle
• Superheterodyne (common); ZF/IF 104 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 103; 111; 118; 127; 135; 143; 155; 186; 210; 225; 240; 253 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch

• Power out
• 3.1 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 521A - Philips Belgium Belgien

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 350 x 265 x 210 mm / 13.8 x 10.4 x 8.3 inch

• Source of data
• -- Original-techn. papers.

• Mentioned in
• La Radio-Industrie, August 1934, p. 317

• Author
• Model page created by Gidi Verheijen. See "Data change" for further contributors.
