655A

655A; Philips; Eindhoven (ID = 41604) Radio

655A; Philips; Eindhoven (ID = 41606) Radio

655A; Philips; Eindhoven (ID = 41605) Radio

655A; Philips; Eindhoven (ID = 41607) Radio

655A; Philips; Eindhoven (ID = 41608) Radio

655A; Philips; Eindhoven (ID = 41609) Radio

655A; Philips; Eindhoven (ID = 41610) Radio
655A; Philips; Eindhoven (ID = 2444866) Radio 655A; Philips; Eindhoven (ID = 2399949) Radio
655A; Philips; Eindhoven (ID = 2311315) Radio 655A; Philips; Eindhoven (ID = 2444868) Radio
655A; Philips; Eindhoven (ID = 2444870) Radio 655A; Philips; Eindhoven (ID = 2444873) Radio
Use red slider bar for more.
655A; Philips; Eindhoven (ID = 2444866) Radio
Philips; Eindhoven: 655A [Radio] ID = 2444866 1142x857
Select picture or schematic to display from thumbnails on the right and click for download.
For model 655A, Philips; Eindhoven (tubes international!); Miniwatt:
Das Radio habe ich von einem Nachbarn geschenkt bekommen,leider ohne die Knöpfe des Lautstärkereglers und der Senderwahl, die jetzt montierten entsprechen wahrscheinlich nicht dem Original.

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1940/1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH3 EF9 EBL1 AZ1
Main principle Superheterodyne (common); ZF/IF 128 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 655A - Philips; Eindhoven tubes
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 490 x 330 x 250 mm / 19.3 x 13 x 9.8 inch
Notes Eingangsbandfilter für MW und LW. Für KW 6 Kreise.
Net weight (2.2 lb = 1 kg) 9.3 kg / 20 lb 7.8 oz (20.485 lb)
Source of data Technisch- Commercieel - Radio Vademecum Staleman

Model page created by Iven Müller. See "Data change" for further contributors.
