831A

831A; Philips Italy; (ID = 1900002) Radio
831A; Philips Italy; (ID = 124087) Radio 831A; Philips Italy; (ID = 1624729) Radio
831A; Philips Italy; (ID = 84652) Radio 831A; Philips Italy; (ID = 391251) Radio
831A; Philips Italy; (ID = 1099702) Radio 831A; Philips Italy; (ID = 1099703) Radio
831A; Philips Italy; (ID = 1099704) Radio 831A; Philips Italy; (ID = 1099705) Radio
831A; Philips Italy; (ID = 1099706) Radio 831A; Philips Italy; (ID = 1099707) Radio
Use red slider bar for more.
831A; Philips Italy; (ID = 124087) Radio
Philips Italy;: 831A [Radio] ID = 124087 604x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model 831A, Philips Italy; Milano (MI)

Country:  Italy
Manufacturer / Brand:  Philips Italy; Milano (MI)
Year: 1932/1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: E452 E452 E424 C443 506
Main principle Superheterodyne (common)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 831A - Philips Italy; Milano MI
Material Wooden case
Shape Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
Dimensions (WHD) 410 x 490 x 210 inch / 10414 x 12446 x 5334 mm
Notes Superinduttanza. Presa fono e per altoparlanti supplementari. Mobile in noce.
Price in first year of sale 1'325.00 ITL
Source of data Guida Pratica Antique Radio II (2000)
Mentioned in -- Original prospect or advert
Literature/Schematics (1) Elettronica Flash, n.11, Novembre 1988

Model page created by Alessandro De Poi. See "Data change" for further contributors.
