835A

835A; Philips Italy; (ID = 254164) Radio

835A; Philips Italy; (ID = 319126) Radio
835A; Philips Italy; (ID = 257574) Radio 835A; Philips Italy; (ID = 328544) Radio
835A; Philips Italy; (ID = 328545) Radio 835A; Philips Italy; (ID = 328658) Radio
835A; Philips Italy; (ID = 328659) Radio 835A; Philips Italy; (ID = 328660) Radio
835A; Philips Italy; (ID = 328661) Radio 835A; Philips Italy; (ID = 328662) Radio
835A; Philips Italy; (ID = 328663) Radio 835A; Philips Italy; (ID = 328664) Radio
Use red slider bar for more.
835A; Philips Italy; (ID = 257574) Radio
Philips Italy;: 835A [Radio] ID = 257574 567x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model 835A, Philips Italy; Milano (MI)

Country:  Italy
Manufacturer / Brand:  Philips Italy; Milano (MI)
Year: 1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: E455 E462 E499 C453 1823
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 103-253 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 835A - Philips Italy; Milano MI
Material Wooden case
Shape Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
Notes Super-Induttanza. Lo schema si riferisce al modello francese, che prevedeva anche le onde lunghe - meno diffuse in Italia, la versione italiana riceve pertanto le sole onde medie.
Super-inductance. The schematics refer to the similar French version of Philips 835A, which can receive long waves. Italian version is a broadcast only receiver.
Source of data Guida Pratica Antique Radio II (2000)
Literature/Schematics (1) -- Schematic

Model page created by Alessandro De Poi. See "Data change" for further contributors.



All listed radios etc. from Philips Italy; Milano (MI)
Here you find 370 models, 306 with images and 229 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
