For model 90AL990 /00, Philips Hong Kong

Country:  Hong Kong
Manufacturer / Brand:  Philips Hong Kong
Year: 1982 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present. TA7208 SN74LS293 SP8601 TBA570 MC14069 MC14016 LM1800 CD4011
Main principle Superhet, double/triple conversion
Wave bands Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
Details
Power type and voltage Line plus power jack, mostly with battery or storage battery / 110-220 / 12 / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 4.2 W (unknown quality)
from Radiomuseum.org Model: 90AL990 /00 - Philips Hong Kong
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 340 x 280 x 140 mm / 13.4 x 11 x 5.5 inch
Notes

Multiband Receiver Philips 90AL990 /00.

AM IF and 2nd IF for SW1-SW5: 468 kHz; 1st IF 2.0 MHz for SW1-SW5 only.
FM IF 10.7 MHz.

See also the Dutch Philips model page 90AL990 /00 /01 /40 /51.

Mentioned in -- Original-techn. papers.

Model page created by Gidi Verheijen. See "Data change" for further contributors.
