• Country
• Switzerland

• Manufacturer / Brand
• Philips - Schweiz

• Year
• 1942/1943

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 13334

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• EF8 ECH3 EBF2 EF9 EM4 EL3 AZ1

• Main principle
• Superhet with RF-stage; ZF/IF 452 kHz; 2 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 26 cm = 10.2 inch

• Power out
• 4.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 910A - Philips - Schweiz

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 940 x 800 x 430 mm / 37 x 31.5 x 16.9 inch

• Notes
• Chassis like Philips 900X but with different output transformer. Can also be used on DC (110-245 V) with 7882C.

  Record changer Philips P25 (110 or 220V). See technical documents with this model.

• Net weight (2.2 lb = 1 kg)
• 41.6 kg / 91 lb 10.1 oz (91.63 lb)

• Price in first year of sale
• 1,500.00 SFr

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Circuit diagram reference
• Die «Thali Schemasammlung» führt das Modell.
