For model 913A, Philips; Eindhoven (tubes international!); Miniwatt:
The build in Garrard AC6a is not the original one. Garrard RC60 is the original one.

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1947/1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EF9 ECH4 EBF2 EF9 EM4 EL3 AZ1
Main principle Superhet with RF-stage; ZF/IF 452 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 4.5 W (unknown quality)
from Radiomuseum.org Model: 913A - Philips; Eindhoven tubes
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 940 x 810 x 430 mm / 37 x 31.9 x 16.9 inch
Notes

With Garrard RC60-H16 (220 volt) automatic record player / changer.



Net weight (2.2 lb = 1 kg) 44 kg / 96 lb 14.7 oz (96.916 lb)
Price in first year of sale 1'450.00 Hfl
Source of data Technisch- Commercieel - Radio Vademecum Staleman
Literature/Schematics (1) -- Original-techn. papers.
