932A

932A; Philips; Eindhoven (ID = 35633) Radio

932A; Philips; Eindhoven (ID = 35634) Radio
932A; Philips; Eindhoven (ID = 102709) Radio 932A; Philips; Eindhoven (ID = 102711) Radio
932A; Philips; Eindhoven (ID = 139520) Radio 932A; Philips; Eindhoven (ID = 139521) Radio
932A; Philips; Eindhoven (ID = 1038020) Radio 932A; Philips; Eindhoven (ID = 1038021) Radio
932A; Philips; Eindhoven (ID = 1038022) Radio 932A; Philips; Eindhoven (ID = 1038023) Radio
932A; Philips; Eindhoven (ID = 1043543) Radio 932A; Philips; Eindhoven (ID = 1043544) Radio
Use red slider bar for more.
932A; Philips; Eindhoven (ID = 102709) Radio
Philips; Eindhoven: 932A [Radio] ID = 102709 524x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model 932A, Philips; Eindhoven (tubes international!); Miniwatt:
The Front

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1932/1933 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: E452T E438 E438 B443 1823
Main principle TRF with regeneration
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 103-253 Volt
Loudspeaker Magnetic loudspeaker (reed) generic.
Power out
from Radiomuseum.org Model: 932A - Philips; Eindhoven tubes
Material Special material, described in the notes.
Shape Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
Notes

Lang- und Mittelwelle in 3 sich überlappenden Bereichen schaltbar. Aperiodische HF-Vorstufe.

Gehäuse aus Arbolite.

Price in first year of sale 160.00 hfl
Source of data Overzicht v.de toe te p PHILIPS
Mentioned in Technisch- Commercieel - Radio Vademecum Staleman
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Iven Müller. See "Data change" for further contributors.
