947A-23

947A-23; Philips Finland - (ID = 502371) Radio 947A-23; Philips Finland - (ID = 502372) Radio
947A-23; Philips Finland - (ID = 502374) Radio 947A-23; Philips Finland - (ID = 502375) Radio
947A-23; Philips Finland - (ID = 502376) Radio 947A-23; Philips Finland - (ID = 502377) Radio
947A-23; Philips Finland - (ID = 502379) Radio
Use red slider bar for more.
947A-23; Philips Finland - (ID = 502371) Radio
Philips Finland -: 947A-23 [Radio] ID = 502371 664x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model 947A-23, Philips Finland - see also Fenno and TeRate

Country:  Finland
Manufacturer / Brand:  Philips Finland - see also Fenno and TeRate
Year: 1935 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: E499 E438 C443 1801
Main principle TRF with regeneration; 2 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110 - 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 947A-23 - Philips Finland - see also
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 345 x 375 x 205 mm / 13.6 x 14.8 x 8.1 inch
Net weight (2.2 lb = 1 kg) 7.6 kg / 16 lb 11.8 oz (16.74 lb)
Source of data - - Data from my own collection

Model page created by Juhani Makivuoti † 21.09.13. See "Data change" for further contributors.



All listed radios etc. from Philips Finland - see also Fenno and TeRate
Here you find 159 models, 149 with images and 38 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
