For model Aachen Luxus D24T915, Philips Radios - Deutschland:
Prospekt: Die Farbgetreuen von Philips, Farbfernseh- und Schwarz-Weiß-Geräte 1969

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1969 Category: Television Receiver (TV) or Monitor
Valves / Tubes 10: PCL86 PCL84 PCF802 PL504 PY88 DY802 PCH200 PC92 PL805
Semiconductors (the count is only for transistors) 13:
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Aachen Luxus D24T915 - Philips Radios - Deutschland
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes 29 Dioden; 1 IC. VHF-Band I und III, UHF-Band IV. Gerät ist mit Chassis D6V ausgerüstet.
Mentioned in -- Original-techn. papers.

Model page created by Franz Born †. See "Data change" for further contributors.
