Adagio 03RB363 /00 /70

Adagio 03RB363 /00 /70; Philips - Österreich (ID = 918618) Radio

Adagio 03RB363 /00 /70; Philips - Österreich (ID = 918619) Radio

Adagio 03RB363 /00 /70; Philips - Österreich (ID = 918621) Radio

Adagio 03RB363 /00 /70; Philips - Österreich (ID = 2400989) Radio

Adagio 03RB363 /00 /70; Philips - Österreich (ID = 2400990) Radio
Adagio 03RB363 /00 /70; Philips - Österreich (ID = 974817) Radio Adagio 03RB363 /00 /70; Philips - Österreich (ID = 446855) Radio
Adagio 03RB363 /00 /70; Philips - Österreich (ID = 446856) Radio Adagio 03RB363 /00 /70; Philips - Österreich (ID = 446857) Radio
Adagio 03RB363 /00 /70; Philips - Österreich (ID = 74412) Radio Adagio 03RB363 /00 /70; Philips - Österreich (ID = 940111) Radio
Adagio 03RB363 /00 /70; Philips - Österreich (ID = 989802) Radio Adagio 03RB363 /00 /70; Philips - Österreich (ID = 990690) Radio
Adagio 03RB363 /00 /70; Philips - Österreich (ID = 990751) Radio Adagio 03RB363 /00 /70; Philips - Österreich (ID = 1397786) Radio
Use red slider bar for more.
Adagio 03RB363 /00 /70; Philips - Österreich (ID = 974817) Radio
Philips - Österreich: Adagio 03RB363 /00 /70 [Radio] ID = 974817 933x342
Select picture or schematic to display from thumbnails on the right and click for download.
For model Adagio 03RB363 /00 /70, Philips - Österreich:
Sammlung Albert Weiss

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1965–1967 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH81 EBF89 ECL86 EM87
Semiconductors (the count is only for transistors) 2: AF124 AF125
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz; 2 AF stage(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker 2 Loudspeakers
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Adagio 03RB363 /00 /70 - Philips - Österreich
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 640 x 195 x 165 mm / 25.2 x 7.7 x 6.5 inch
Notes Zwei Ausführungen: /00 = dunkel hochglänzend, /70 = hell matt.
Price in first year of sale 1'995.00 öS
Collectors' prices
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb

Model page created by Wolfgang Bauer. See "Data change" for further contributors.



All listed radios etc. from Philips - Österreich
Here you find 1052 models, 987 with images and 845 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
