Adagio 03RB373 /00 /02

Adagio 03RB373 /00 /02; Philips - Österreich (ID = 918636) Radio

Adagio 03RB373 /00 /02; Philips - Österreich (ID = 918637) Radio

Adagio 03RB373 /00 /02; Philips - Österreich (ID = 918638) Radio

Adagio 03RB373 /00 /02; Philips - Österreich (ID = 918635) Radio

Adagio 03RB373 /00 /02; Philips - Österreich (ID = 2400991) Radio
Adagio 03RB373 /00 /02; Philips - Österreich (ID = 982789) Radio Adagio 03RB373 /00 /02; Philips - Österreich (ID = 74414) Radio
Adagio 03RB373 /00 /02; Philips - Österreich (ID = 982790) Radio
Use red slider bar for more.
Adagio 03RB373 /00 /02; Philips - Österreich (ID = 982789) Radio
Philips - Österreich: Adagio 03RB373 /00 /02 [Radio] ID = 982789 932x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model Adagio 03RB373 /00 /02, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1965/1966 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH81 EBF89 ECL86 EM87
Semiconductors (the count is only for transistors) 2: AF124 AF125
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz; 2 AF stage(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker 2 Loudspeakers
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Adagio 03RB373 /00 /02 - Philips - Österreich
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 640 x 195 x 165 mm / 25.2 x 7.7 x 6.5 inch
Notes 2 Ausführungen /00 = dunkel hochglänzend, /02 = hell matt.
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
