AG9148/19A

AG9148/19A; Philips, Svenska AB, (ID = 869095) R-Player AG9148/19A; Philips, Svenska AB, (ID = 869096) R-Player
AG9148/19A; Philips, Svenska AB, (ID = 869097) R-Player AG9148/19A; Philips, Svenska AB, (ID = 869098) R-Player
AG9148/19A; Philips, Svenska AB, (ID = 869099) R-Player AG9148/19A; Philips, Svenska AB, (ID = 869100) R-Player
Use red slider bar for more.
AG9148/19A; Philips, Svenska AB, (ID = 869095) R-Player
Philips, Svenska AB,: AG9148/19A [R-Player] ID = 869095 933x620
Select picture or schematic to display from thumbnails on the right and click for download.
For model AG9148/19A, Philips, Svenska AB, Stockholm

Country:  Sweden
Manufacturer / Brand:  Philips, Svenska AB, Stockholm
Year: 1960 ?? Category: Sound/Video Recorder and/or Player
Valves / Tubes 2: UCL82 UY85
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: AG9148/19A - Philips, Svenska AB, Stockholm
Material Leather / canvas / plastic - over other material
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 370 x 140 x 240 mm / 14.6 x 5.5 x 9.4 inch
Notes 4 speed: 16, 33, 45 and 78 rpm. Double side needle which is turned over, to play micro-tracks or normal tracks.
Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Collectors' prices
Source of data - - Data from my own collection

Model page created by Jörgen Svensson. See "Data change" for further contributors.
