AL641LH

AL641LH; Philips Argentina, (ID = 980058) Radio AL641LH; Philips Argentina, (ID = 980059) Radio
AL641LH; Philips Argentina, (ID = 980060) Radio AL641LH; Philips Argentina, (ID = 980061) Radio
AL641LH; Philips Argentina, (ID = 980062) Radio AL641LH; Philips Argentina, (ID = 980063) Radio
AL641LH; Philips Argentina, (ID = 2070545) Radio
Use red slider bar for more.
AL641LH; Philips Argentina, (ID = 980058) Radio
Philips Argentina,: AL641LH [Radio] ID = 980058 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model AL641LH, Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires:
Este ejemplara pertenece al Ing. Domingo Ricillo. Don Torcuato-Argentina

Country:  Argentina
Manufacturer / Brand:  Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires
Year: 1947 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: OH4 OF5 OBC3 50L6 35Z5
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 110/220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: AL641LH - Philips Argentina, FAPESA,
Material Wooden case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 330 x 230 x 145 mm / 13 x 9.1 x 5.7 inch
Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)

Model page created by Heriberto Tavella. See "Data change" for further contributors.
