Ambassador-Luxus 23TA441A /01 /71 Ch= P6

Ambassador-Luxus 23TA441A /01 /71 Ch= P6; Philips - Österreich (ID = 270188) Television

Ambassador-Luxus 23TA441A /01 /71 Ch= P6; Philips - Österreich (ID = 270189) Television

Ambassador-Luxus 23TA441A /01 /71 Ch= P6; Philips - Österreich (ID = 1986285) Television
Ambassador-Luxus 23TA441A /01 /71 Ch= P6; Philips - Österreich (ID = 153957) Television
Use red slider bar for more.
Ambassador-Luxus 23TA441A /01 /71 Ch= P6; Philips - Österreich (ID = 153957) Television
Philips - Österreich: Ambassador-Luxus 23TA441A /01 /71 Ch= P6 [Television] ID = 153957 704x592
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ambassador-Luxus 23TA441A /01 /71 Ch= P6, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1964/1965 Category: Television Receiver (TV) or Monitor
Valves / Tubes 18: PCC189 PCF86 EF183 PCF200 PCF200 PCL84 PCL85 PCL86 ECH84 PCF80 PF86 PCL85 ECH84 PCF802 PL500 PY88 DY87 A59-11W
Semiconductors (the count is only for transistors) 6: AF186 AF186 AF126 AF126 AF126 AC125
Main principle Super-Heterodyne (Super in general)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 190-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Ambassador-Luxus 23TA441A /01 /71 Ch= P6 - Philips - Österreich
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 660 x 520 x 355 mm / 26 x 20.5 x 14 inch
Notes

Fernsehband VHF (I+III), UHF (IV/V). 59-cm-Rechteckbildröhre.
2 Ausführungen:
/01= Edelholzkassette dunkel-hochglänzend;
/71= hell-matt.

Paralleltype zum Horny W59T144A.

Net weight (2.2 lb = 1 kg) 30 kg / 66 lb 1.3 oz (66.079 lb)
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
