AM/FM Radio Cassette Recorder D7012

AM/FM Radio Cassette Recorder D7012; Philips - Österreich (ID = 2617338) Radio AM/FM Radio Cassette Recorder D7012; Philips - Österreich (ID = 2617345) Radio
AM/FM Radio Cassette Recorder D7012; Philips - Österreich (ID = 2617340) Radio AM/FM Radio Cassette Recorder D7012; Philips - Österreich (ID = 2617343) Radio
AM/FM Radio Cassette Recorder D7012; Philips - Österreich (ID = 2617346) Radio AM/FM Radio Cassette Recorder D7012; Philips - Österreich (ID = 2617348) Radio
Use red slider bar for more.
AM/FM Radio Cassette Recorder D7012; Philips - Österreich (ID = 2617338) Radio
Philips - Österreich: AM/FM Radio Cassette Recorder D7012 [Radio] ID = 2617338 1400x951
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM/FM Radio Cassette Recorder D7012, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1983 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: BF495 BF495 BF495 BF494 BF495 BF495 TDA1012
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110-127; 220-240 / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: AM/FM Radio Cassette Recorder D7012 - Philips - Österreich
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes

Siehe auch das niederländische Modell Philips D7012 /00 /05.

Mentioned in - - Manufacturers Literature

Model page created by Manfred Rathgeb. See "Data change" for further contributors.
