B2G90U

B2G90U; Philips Electrical, (ID = 577216) Radio

B2G90U; Philips Electrical, (ID = 577217) Radio

B2G90U; Philips Electrical, (ID = 577219) Radio
Use red slider bar for more.
B2G90U; Philips Electrical, (ID = 577216) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Philips Electrical, Lamps, Industrial - Miniwatt; London
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UF41 UBC41 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110-127 / 200-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: B2G90U - Philips Electrical, Lamps,
Material Plastics (no bakelite or catalin)
Shape Tablemodel, with any shape - general.
Price in first year of sale 19.00 GBP
Source of data -- Schematic
Circuit diagram reference Radio and TV Servicing books (R&TVS) book
Literature/Schematics (1) ERT Sheet 1198.

Model page created by Keith Staines. See "Data change" for further contributors.
