For model B2X72U /00 /01, Philips; Eindhoven (tubes international!); Miniwatt:
From the collection of Hans van Iterson, The Netherlands

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1957/1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCC85 UCH81 UF89 UABC80 UL84 UY85
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage AC/DC-set / 110-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: B2X72U /00 /01 - Philips; Eindhoven tubes
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 334 x 205 x 190 mm / 13.1 x 8.1 x 7.5 inch
Notes
AM radio with built-in ferroceptor:
  • BC: 517 - 1620 kHz.
FM radio with dipole antenna input: 87.5 - 100 MHz.

Oval loudspeaker AD2460M.
Dial lamp: 8005D-00 (18V / 100mA).

Difference between versions /00 and /01:
  • /00: 220V mains.
  • /01: 110-127V mains.
Net weight (2.2 lb = 1 kg) 3.4 kg / 7 lb 7.8 oz (7.489 lb)
Price in first year of sale 178.00 HFL
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Iven Müller. See "Data change" for further contributors.
