B2X80U /01

B2X80U /01; Philips; Eindhoven (ID = 1615958) Radio

B2X80U /01; Philips; Eindhoven (ID = 1615959) Radio

B2X80U /01; Philips; Eindhoven (ID = 1615960) Radio

B2X80U /01; Philips; Eindhoven (ID = 1615961) Radio

B2X80U /01; Philips; Eindhoven (ID = 1615962) Radio

B2X80U /01; Philips; Eindhoven (ID = 1615963) Radio

B2X80U /01; Philips; Eindhoven (ID = 1615964) Radio
B2X80U /01; Philips; Eindhoven (ID = 2550434) Radio B2X80U /01; Philips; Eindhoven (ID = 828383) Radio
B2X80U /01; Philips; Eindhoven (ID = 246387) Radio B2X80U /01; Philips; Eindhoven (ID = 812467) Radio
B2X80U /01; Philips; Eindhoven (ID = 812470) Radio B2X80U /01; Philips; Eindhoven (ID = 814194) Radio
B2X80U /01; Philips; Eindhoven (ID = 1288090) Radio B2X80U /01; Philips; Eindhoven (ID = 1288091) Radio
B2X80U /01; Philips; Eindhoven (ID = 1288092) Radio
Use red slider bar for more.
B2X80U /01; Philips; Eindhoven (ID = 2550434) Radio
Philips; Eindhoven: B2X80U /01 [Radio] ID = 2550434 1400x728
Select picture or schematic to display from thumbnails on the right and click for download.
For model B2X80U /01, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1958/1959 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH81 UF89 UBC81 UL84 UY42
Main principle Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage AC/DC-set / 110-127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 11 cm = 4.3 inch
Power out
from Radiomuseum.org Model: B2X80U /01 - Philips; Eindhoven tubes
Material Bakelite case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 315 x 179 x 145 mm / 12.4 x 7 x 5.7 inch
Notes
AM radio with built-in ferroceptor:
  • LW: 150 - 260 kHz.
  • BC: 517 - 1610 kHz.
Loudspeaker AD2500X.
Dial lamp: 8009D-07 (6,3V / 250mA).

This model looks like the B2X80U, but it has a cream coloured case and a bleu dial. The B2X80U has a black case and a red dial.
See also others variations on this model B2X80UB2X80U/03 and B2X80U/04.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Jos van den Broek. See "Data change" for further contributors.



All listed radios etc. from Philips; Eindhoven (tubes international!); Miniwatt
