For model B3X91T /00K /00L, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1959/1960 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: OC170 OC45 OC45 OC71 OC71 OC72 OC72
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Dry Batteries / 6x1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: B3X91T /00K /00L - Philips; Eindhoven tubes
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 342 x 210 x 175 mm / 13.5 x 8.3 x 6.9 inch
Notes

LW: 150-400 kHz (750-2000 m)
MW: 517-1622 kHz (185-580 m)
SW2b: 3,7-7,6 MHz (40-81 m)
SW2a: 7,6-15,5 MHz (19-40 m)

Differences between variants /00K and /00L: Cabinet and dial.

Unterschiede der Varianten /00K und /00L: Gehäuse und Skala.

Source of data -- Original-techn. papers.
