For model B4F70A, Philips France; Paris

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH81 EBF80 ECL82 EZ80 EM81
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: B4F70A - Philips France; Paris
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 477 x 327 x 185 mm / 18.8 x 12.9 x 7.3 inch
Notes

4 gammes d'ondes: GO de 1100 à 1950 m, PO de 185 à 572 m, OC de 16.5 à 51 m, et BE (bande étalée) de 47 à 50.5 m. Cadre ferrite integré orientable. Clavier 5 touches éclairés. Ampoules cadran 2 x 8045D/00 (6,3 V - 0,3 A).

Modèle prévu pour montage d'adaptateur chalutier FD 002 79 (gamme de 80 à 200 m).

Il existe aussi un modèle B4F70A /03 avec oeil magique différent et des dimensions réduits.

Net weight (2.2 lb = 1 kg) 6.250 kg / 13 lb 12.3 oz (13.767 lb)
Mentioned in -- Original-techn. papers.

Model page created by Mark Hippenstiel. See "Data change" for further contributors.
